Nonlinear reduced order models using linear modal components animation

Nonlinear reduced order models using linear modal components animation

Highly reduced order models with nonlinear contact – extremely efficient computation. Modeled as linear components interconnected with highly reduced order components.

reduced order nonlinear contact animations

1-linear reduced model, 2-contact to ground, 3-component to component single contact, 4 component to component multiple contacts

1-linear reduced model2-contact to ground

3-component to component single contact4-component to component multiple contacts
